High-Performance Sony IMX678 MIPI Camera MCI080-MIPI Camera Module CSI-2 Output
MCI080-MIPI-HXXX camera module Featuring the high-performance Sony IMX678 CMOS sensor, this module delivers exceptional imaging quality. It comes equipped with a factory-focused and secured M12 lens to ensure optical stability and precision. Designed for versatility, the module supports seamless integration across a wide range of SoC platforms.
Application :
Machine-vision
Intelligent transportation
Aeronautics and Astronautics
Industrial inspection
Advantages
Output format: Uncompressed RAW format
Industrial high performance
Support different focal length lens
Support external triggering
Multi−Camera synchronization
Resources
Technical Data
| Model | MCI080-MIPI-HXXX |
| Resolution | 3840H*2160V |
| Frame Rate | Up to 60 fps |
| Support Platorm | Jetson AGX Thor & Orin |
| Sensor | SONY 8.29 MP IMX678 RGGB |
| Output data | MIPI/RAW@10bit/12bit |
| Sensor Type | Rolling Shutter |
| Operating temp.range | -30°C～+85°C |
| Dimensions | 20mm*35mm*25mm |
| FOV | HFOV 29°/57°/124° |
| Weight | <50g |
