Thermal Imaging
|
|
Detector Type
|
Uncooled infrared detector
|
|
Infrared Resolution
|
640×512
|
|
Pixel Size
|
12μm
|
|
Super Resolution
|
1280×1024
|
|
Spectral Band
|
7.5-14μm
|
|
NETD
|
＜35mK (25°C,F1.0)
|
|
Frame Rate
|
25 Hz
|
|
Lens Focal Length
|
Standard lens: 17.7mm; super telephoto lens: 60.9mm; telephoto lens: 31.5mm; wide-angle lens: 9.5mm; macro lens (0.2×): 13mm; super macro lens (0.4×): 14.8mm.
|
|
FOV
|
Standard lens: 25°×20°; super telephoto lens: 7°×5.6°; telephoto lens: 14°×11.2°; wide-angle lens: 45°×36°.
|
|
IFOV
|
Standard lens: 0.68mrad; super telephoto lens: 0.2mrad; telephoto lens: 0.38mrad; wide-angle lens: 1.26mrad; Macro lens: One pixel corresponds to 60μm; super macro lens: One pixel corresponds to 30μm.
|
|
Focusing Mode
|
Electric micro focus, manual focusing, one-button center focus, automatic center focus, single-touch automatic focusing, laser-assisted focus
|
|
Measurement Range
|
-20°C~+150°C, 100°C~650°C; optional: 400°C~+1500°C
|
|
Measurement Accuracy
|
±2°C or ±2% of readings, whichever is greater
|
|
|
Imaging Display
|
|
Display
|
5-inch OLED touch screen, resolution 1280×720
|
|
Visible Light Camera
|
13 megapixels
|
|
Digital Zoom
|
1× ~ 10×
|
|
Palettes
|
19 options
|
|
Image Mode
|
Infrared, visible light, PIP, dual-spectrum fusion
|
|
Temperature Width Stretch
|
Support
|
|
|
Image Storage
|
|
Storage Medium
|
Standard 64GB Micro SD, Support SD, SDHC, SDXC,up to 2TB
|
|
Text Notes
|
Support
|
|
Voice Annotation
|
Support
|
|
|
Measurement and Analysis
|
|
Analysis Functions on the Device
|
Support up to 20 movable points, lines, frames, circles and polygons, and up to 5 preset modes
|
|
Laser Rangefinding
|
Support
|
|
Area Measurement
|
Support
|
|
Hygrothermograph
|
Support
|
|
Position
|
Support
|
|
Temperature Difference Analysis
|
Support
|
|
Trend Analysis
|
Supports temperature trend recording and analysis.
|
|
Image Freezing
|
Support
|
|
Analysis Report
|
PDF format. Support editing and template importing on the PC client.
|
|
Supporting Software
|
PC (Infrared Analysis Software) & Mobile Device (iOS/Android APP)
|
|
|
Video Functions
|
|
Radiation Infrared Video Recording
|
Support compressed full radiation video recording (.irv), up to 25Hz video recording.
|
|
Non-radiation Infrared or Visible Light Video Recording
|
Standard MP4 video recording
|
|
Radiation Infrared Video Stream Transmission
|
TYPE-C/WLAN connection to PC, for real-time transmission of radiation infrared video streams
|
|
Non-radiation Infrared Video Stream Transmission
|
RTSP H.264
|
|
Video Resolution
|
1280×720
|
|
|
System Functions
|
|
Intelligent Image Stabilization
|
Support
|
|
Intelligent Panoramic Stitching
|
Support panoramic stitching on the PC client, and one-click synthesis.
|
|
Intelligent Routine Inspection
|
Support. General task package import and editing, standard and automatic naming of images
|
|
Routine Inspection Record Self-inspection
|
Support
|
|
Dual-Spectrum Video Recording
|
Simultaneous infrared video and visible light video recording, in MP4 format.
|
|
Communication Protocol
|
Wi-Fi, Bluetooth, USB, DP, Type-C to HDMI
|
|
Voice Control
|
Voice assistant, quick command recognition
|
|
Flashlight
|
Support
|
|
|
Others
|
|
Microphone/Speaker
|
Support
|
|
Battery
|
10,000mAh lithium-ion battery, field-replaceable, support fast charging
|
|
Charging Mode
|
USB Type-C or desktop charger
|
|
Battery Life
|
Continuous operating time ≥ 6 hours (depending on the actual environment and service conditions)
|
|
Interface
|
USB3.0 Type-C, SD card, SIM card, Mini HDMI
|
|
Tripod Socket
|
UNC 1/4-20 interface for tripod
|
|
Operating Temperature
|
-20°C~+55°C
|
|
Operating Humidity
|
10%~95% (non-condensing)
|
|
Storage Temperature
|
-40°C~+70°C
|
|
Ingress Protection Rating
|
IP54
|
|
Shock and Vibration
|
Shock: 25g (IEC 60068-2-27); vibration: 2.5g (IEC60068-2-6)
|
|
Weight and Dimensions
|
About 1.3kg (with battery), 144×129×307mm
|
|
Authentication
|
CE/RoHS/CMA, etc.
|
|
Packing List
|
Thermal camera, standard lens, lithium-ion battery×2, charging stand, charger (with plug for use in multiple countries), charging cable,
Bluetooth headset, SD card 64G, Type-C cable, lens hood, mold drawing, data download card, calibration certificate, certificate of
qualification, hand strap (with buckle), safety box, lens cap (with screws).
|
|
PRODUCT NUMBER
|
MCI039
|
|
